PULL BLADES
- All pull blades feature a solid shaft bullet in your choice of diameter: 1 1/2”, 2”, and 2½” (Larger, optional sizes available upon request)
- Blade shank thickness is 1 ½”
- Standard depths are 30”, 36”, 42” and 48”
CHUTED BLADES
- Blade shank thickness is 1 ½”
- All standard blades feature a closed bottom unless you specify open or partially open bottom
LARGER RADIUS PLOW BLADES- cable TV, fiber optics, etc.
- Standard inside chutes – 1 ½”, 2”, 2 ½”, 3” and 3 ½”
- Standard radius is 10”, 12.5” and 15”
- Standard cover depths are 36” and 42”
GAS BLADES – for plastic gas pipe, w/wire and ribbon tubes
- Standard inside chutes – 2”, 2 ½” and 3”
- Standard gas radius
- Standard cover depths are 36” and 42”
3 PHASE POWER BLADES – for multiple power cables
- Standard inside chutes – 1 ½” x 4 ½”, 1 ¾” x 5 ¼” and 2” x 6”
- 3 phase radius
- Standard cover depths are 36” and 42”
