Will fit the Ditch Witch* RT50 and the RT55
PULL BLADES
- All pull blades feature a solid shaft bullet in your choice of diameter: 1 ½”, 2”, 2 ½” (Larger, optional sizes available upon request)
- Blade shank thickness is ¾”up to 36” cover and 1” from 36”-48” cover
- Standard depths are 6” increments, 18”-24’, 24”-30”, 30”-36”, 36”-42”, and 42”-48”
CHUTED BLADES
- Blade shank thickness is ¾” up to 36” and 1” from 36”-48” cover
- All standard blades feature a closed bottom unless you specify open or partially open bottom
BUG WIRE OR DROP BLADES
- Standard inside chutes – ¾” and 1”
- Standard radius is 2.5” and 4.5”
- Standard cover depths are 18”-24”, 24”-30”, 30”-36” and 36”-42”
STANDARD PLOW BLADES
- Standard inside chutes – ¾”, 1”, 1 ¼”, 1 ½”, 1 ¾” and 2”
- Standard radius is 7.5”
- Standard cover depths are 18”-24”, 24”-30”, 30”-36” and 36”-42”
LARGER RADIUS PLOW BLADES – cable TV, fiber optics, etc.
- Standard inside chutes – 1”, 1 ¼”, 1 ½”, 1 ¾”, 2”, 2 ½” and 3”
- Standard radius is 10”, 12.5”, and 15”
- Standard cover depths are 18”-24”, 24”-30”, 30”-36” and 36”-42”
GAS BLADES – for plastic gas pipe, w/wire and ribbon tubes
- Standard inside chutes – 1”, 1 ½”, 2”, 2 ½” and 3”
- Standard gas radius
- Standard cover depths are 18”-24”, 24”-30”, 30”-36” and 36”-42”
3 PHASE POWER BLADES – for multiple power cables
- Standard inside chutes – 1 ½” x 4 ½”, 1 ¾” x 5 ¼”, 2” x 6”and 2 ½” x 7 ½”
- 3 phase radius
- Standard cover depths are 24”-30”, 30”-36”, 36”-42” and 36”-42”
